EBB N

The EBB-N fans are powerful, domestic extractor fans that are suitable for wall or ceiling mounted installations. These can be either on the surface or flush mounted as well as on surface or built-in installations, designed to solve ventilation problems in all wet rooms. They incorporate a forward curved centrifugal impeller, making them a perfect solution for installations that require higher airflows and encounter higher system resistance, and are also suitable to operate with air temperatures up to 40°C. There are 3 sizes available (100, 170 and 250) with different airflow performances to suit most scenarios. All sizes come with a minimum 2 speed motor, adjustable humidity sensor, adjustable over-run timer and integral backdraught shutter as standard.

Key Features

High Airflow Performance

Forward Curved Centrifugal Impeller

Adjustable Humidity Sensor

Adjustable between 60% - 90%

Adjustable Over-run Timer

Adjustable between 1 - 30 minutes.

Backdraught Shutter

Prevents Air Entry and Reduces Heat Leakage

Multiple Selectable Speeds

2 Speeds (EBB-100N) or 3 Speeds (EBB170N &250N)

Higher Resistance System Capabilities

Suitable for Longer and More Resistive Duct Runs

Product Overview

Max Airflow (l/s)

31, 64, 78

Ducting / Connection Size (mm)

100

Warranty

2

IP Rating

IP44

Request a Quote Find a Stockist
Request a Design Service
CONFIG ON EasyVent

Key Features

  • High Airflow Performance

    Incorporates a forward curved centrifugal impeller, making them a perfect solution for installations that encounter higher system resistance.

  • Adjustable Humidity Sensor

    Adjustable humidity sensor that can be adjusted between 60 - 90% relative humidity. The extract fan will continue to run until the selected level of relative humidity has been reached.

  • Adjustable Over-run Timer

    Over-run timer that can be adjusted between 1 - 30 minutes. This means the fan will continue to run after being switched off to ensure humidity is reduced.

  • Backdraught Shutter

    Backdraught shutter comes as standard, this prevents air entry and limits heat leakage when the fan is not operating.

  • Multiple Selectable Speeds

    Multiple selectable speed that allows the end user to pick the airflow that is best suited for your particular scenario, This will save energy and keep noise to a minimum.

  • Higher Resistance System Capabilities

    EBB N can deliver airflows in systems with higher resistance this is helpful for some scenarios such as internal wet rooms. These rooms often have longer duct runs. Traditional extractor fans are not powerful enough to meet the desired airflow rates.

Product Documents

Product Codes

Product CodeProduct Description
EBB-100N-SStandard
EBB-100N-TAdjustable Timer
EBB-100N-HTAdjustable Humidity Sensor, Adjustable Timer
EBB-170N-HTAdjustable Humidity Sensor, Adjustable Timer
EBB-250N-HTAdjustable Humidity Sensor, Adjustable Timer
