CYCLONE 8
The CYCLONE 8 is a continuous running extractor fan suitable for WCs, bathrooms, utility rooms and kitchens. It is a major advancement in extractor fan technology; it utilises a centrifugal impeller and our Intellitrac technology which ensures extremely high airflow performance and humidity levels are controlled all year round. The CYCLONE 8 is a fully variable speed fan; this makes it the perfect solution for all property sizes and makes meeting the Approved Document F airflow rates as easily as possible. Not only that it also has a datalogging function that allows the end user to track what the fan is doing, this includes: total hours run, total hours run in boost, energy consumption and much more. This is one of the most versatile fans on the market and can be installed on walls, ceilings, windows and even inline making it suitable for every scenario.
Key Features
High Airflow Performance
Up to 55l/s
Low Noise Levels
Down to 12.72 dB(A) @ 3m
Cartridge System
Unique, Easy to Remove and Install
Intellitrac Relative Humidity Control
No User Interaction Required
Datalogging function
Records and Holds Key Running Data About the Fan
8-Year Warranty
Parts Only
Variable Speed Control
Manufactured in the UK
Product Overview
Max Airflow (l/s)
55
Ducting / Connection Size (mm)
100, 150
Warranty
8
IP Rating
IPX4, IP57
SAP PCDB Listed
No
Key Features
High Airflow Performance
High airflow performance up to 55l/s ensures that excess humidity is removed from wet rooms rapidly helping to reduce condesnation and mould within the property.
Low Noise Levels
Quiet Running with sound levels as low as 12.72 dB(A) at 3m under free field conditions.
Cartridge System
Unique, easy to remove cartridge system allowing easy electronic replacements and upgrades if needed. The main body of the fan remains in place eliminating the need to dispose of the whole unit. This reduces the amount of non-biodegradable material thrown into landfill.
Intellitrac Relative Humidity Control
Intellitrac is a unique intelligent vapour tracking control that constantly monitors the humidity levels within the wet room. As humidity rises and falls, the motor speed rises and falls in direct correlation, this ensures humidity levels do not increase. This feature runs constantly in the background meaning the end user does not need to interact with the fan.
Datalogging function
Datalogging function as standard including hours run, time spent in trickle/boost, time spent in periods of increased humidity and the energy usage of the fan.
8-Year Warranty
All Cyclone 8 models come with an 8-year parts only warranty as standard.
Variable Speed Control
Variable speed control as standard using 25 increments from the factory set point up to 100% airflow. This allows the fan speed to be set to every properties individual requirements.
Manufactured in the UK
Manufactured in envirovent's® on-site factory in Harrogate, North Yorkshire
Product Documents
Product Codes
| Product Code | Product Description |
|---|---|
| CYC-DL-230V | 230V, Datalogger |
| CYC-DL-SELV | SELV, Datalogger |
| CYC-DL-IN-IQ | 230V, Datalogger, Inline, Wireless Control |
| CYC-DL-230V-IQ | 230V, Wireless Control |
| CYC-DL-SELV-IQ | SELV, Datalogger, Wireless Control |
Cyclone 8
Frequently Asked Questions
The Cyclone 8 comes as standard with a pull cord, which can be used to boost the fan when appropriate as a manual method of control.
An IQ wireless boost switch is also available.
The Cyclone 8 comes with Intellitrac humidity tracking as standard, which varies the fan speed depending upon the humidity level identified.
The Cyclone 8 comes with a datalogger and variable speed function as standard.
The datalogger shows the amount of time the fan has spent in both trickle and boost speeds, periods of increased humidity, the total running time and energy usage in kWh.
The variable speed control offers 25 settings between trickle and boost at 4% increments. Further information can be found within the installation guide.
The Cyclone 8 is suitable for use with 100mm rigid ducting.
The Cyclone 8 can be installed on the wall, ceiling, inline and in-window making it a flexible ventilation option.
The Cyclone 8 is offered with an impressive eight year warranty as standard.
The Cyclone 8 is available as a low voltage version if required.
The Cyclone 8 must ventilate to the atmosphere with a suitable termination such as a louvred grille or roof tile vent. The chosen termination should be suitable for use with mechanical ventilation.
